Transformation matrix from the setting of the parent structure (a_p,b_p,c_p) to the working setting (a,b,c):

[Hide]

Symmetry operations of the magnetic space group in the setting used:

N	(x,y,z)	Seitz notation
1	x,y,z,+1	{ 1 \| 0 }
2	x,-y,-z,+1	{ 2₁₀₀ \| 0 }
3	-x,-y,-z,+1	{ -1 \| 0 }
4	-x,y,z,+1	{ m₁₀₀ \| 0 }
5	-x,y+1/2,-z,-1	{ 2'₀₁₀ \| 0 1/2 0 }
6	-x,-y+1/2,z,-1	{ 2'₀₀₁ \| 0 1/2 0 }
7	x,-y+1/2,z,-1	{ m'₀₁₀ \| 0 1/2 0 }
8	x,y+1/2,-z,-1	{ m'₀₀₁ \| 0 1/2 0 }
(1/2,1/2,1/2) + set click here to show and hide
9	x+1/2,y+1/2,z+1/2,+1	{ 1 \| 1/2 1/2 1/2 }
10	x+1/2,-y+1/2,-z+1/2,+1	{ 2₁₀₀ \| 1/2 1/2 1/2 }
11	-x+1/2,-y+1/2,-z+1/2,+1	{ -1 \| 1/2 1/2 1/2 }
12	-x+1/2,y+1/2,z+1/2,+1	{ m₁₀₀ \| 1/2 1/2 1/2 }
13	-x+1/2,y,-z+1/2,-1	{ 2'₀₁₀ \| 1/2 0 1/2 }
14	-x+1/2,-y,z+1/2,-1	{ 2'₀₀₁ \| 1/2 0 1/2 }
15	x+1/2,-y,z+1/2,-1	{ m'₀₁₀ \| 1/2 0 1/2 }
16	x+1/2,y,-z+1/2,-1	{ m'₀₀₁ \| 1/2 0 1/2 }

[Hide]

Transformation matrix from the working setting (a,b,c) to the standard setting of the magnetic space group (a_s,b_s,c_s):

[Hide]

Symmetry operations of the magnetic point group in the setting used:

[Hide]

Magnetic atoms:

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Eu1	Eu	0.00000	0.25000	0.71540	4	m_x,0,0	8.0(2)	0.0	0.0	8.00

Non-magnetic atoms:

Label	Atom type	x	y	z	Multiplicity
Pd1	Pd	0.29500	0.00000	0.00000	8
Pd2	Pd	0.25000	0.25000	0.25000	4
Si1	Si	0.00000	0.07860	0.18520	8

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.25000	0.71540	m_x,0,0	8.00000	0.00000	0.00000
2	0.00000	0.75000	0.28460	m_x,0,0	8.00000	0.00000	0.00000
(1/2,1/2,1/2) + set click here to show and hide
3	0.50000	0.75000	0.21540	m_x,0,0	8.00000	0.00000	0.00000
4	0.50000	0.25000	0.78460	m_x,0,0	8.00000	0.00000	0.00000

Atom	x	y	z
1	0.29500	0.00000	0.00000
2	0.70500	0.00000	0.00000
3	0.70500	0.50000	0.00000
4	0.29500	0.50000	0.00000
(1/2,1/2,1/2) + set click here to show and hide
5	0.79500	0.50000	0.50000
6	0.20500	0.50000	0.50000
7	0.20500	0.00000	0.50000
8	0.79500	0.00000	0.50000

Atom	x	y	z
1	0.25000	0.25000	0.25000
2	0.25000	0.75000	0.75000
(1/2,1/2,1/2) + set click here to show and hide
3	0.75000	0.75000	0.75000
4	0.75000	0.25000	0.25000

Atom	x	y	z
1	0.00000	0.07860	0.18520
2	0.00000	0.92140	0.81480
3	0.00000	0.57860	0.81480
4	0.00000	0.42140	0.18520
(1/2,1/2,1/2) + set click here to show and hide
5	0.50000	0.57860	0.68520
6	0.50000	0.42140	0.31480
7	0.50000	0.07860	0.31480
8	0.50000	0.92140	0.68520

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Eu1	Eu	0.00000	0.25000	0.71540	4	m_x,0,0	8.0(2)	0.0	0.0	8.00

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.25000	0.71540	m_x,0,0	8.00000	0.00000	0.00000
2	0.00000	0.75000	0.28460	m_x,0,0	8.00000	0.00000	0.00000
(1/2,1/2,1/2) + set click here to show and hide
3	0.50000	0.75000	0.21540	m_x,0,0	8.00000	0.00000	0.00000
4	0.50000	0.25000	0.78460	m_x,0,0	8.00000	0.00000	0.00000

label	dim. small irrep	dim. full irrep	action	number of modes
mGM3+	1	1	primary	1
